scjson

A JSON-based serialization of SCXML (State Chart XML) for modern tooling, interoperability, and education.

Execution Engines

Python engine: Deterministic trace emitter, vector generation, and compare tools. See docs/ENGINE-PY.md and py/ENGINE-PY-DETAILS.md.
Ruby engine: Trace interface under active development with growing feature parity. See docs/ENGINE-RB.md.

JS/TS Harness (via SCION)

The JS package ships a harness CLI scjson-scion-trace that directly requires scion-core to execute SCXML and emit JSONL traces. Install scion-core in your project to enable it.
Supports both .scxml and .scjson input (the latter is converted to SCXML internally).
Normalization flags: --leaf-only, --omit-delta, --omit-transitions, --strip-step0-noise, --strip-step0-states.
Usage (package): npx scjson-scion-trace -I chart.(scxml|scjson) -e events.jsonl [--xml] [--leaf-only] [--omit-delta] [...]
Dev alternative (in this repo): node tools/scion-runner/scion-trace.cjs -I chart.scxml -e events.jsonl --xml

Overview

scjson is a structured, schema-based representation of SCXML, the W3C standard for state machine modeling. This format preserves the semantics and hierarchy of SCXML while making it more accessible to modern tools, languages, and interfaces.

Why JSON?

Easier to parse in JavaScript, Python, Rust, etc.
Fits naturally with REST APIs, editors, and static validation
Can be round-tripped to and from standard SCXML
Works with compact formats like MessagePack or Protobuf when needed

Goals

💡 Interoperability: Serve as a bridge between SCXML and modern application ecosystems
📦 Portability: Enable translation to binary formats (MessagePack, Protobuf, etc.)
📚 Pedagogy: Make it easier to teach and learn state machines with cleaner syntax and visual tools
🔁 Round-trip Fidelity: Support conversion back to valid SCXML without semantic loss

Schema

The canonical scjson.schema.json file is located in /scjson.schema.json. It is generated from Pydantic models and used to validate all *.scjson documents. Detailed inference rules used by the converters are described in INFERENCE.md.

Directory Structure

Each language implementation lives in its own directory, as a standalone module or library root:

/schema/ → JSON Schema definition of scjson /examples/ → SCXML and scjson sample pairs /tutorial/ → Git submodule: Zhornyak SCXML tutorial /python/ → Python reference implementation (CLI + library) /js/ → JavaScript CLI and library /ruby/ → Ruby CLI and gem /go/ → Go command line utility /rust/ → Rust command line utility /swift/ → Swift command line tool /java/ → Java command line tool /lua/ → Lua scripts /csharp/ → C# command line tool

Each directory is designed to be independently usable as a library or CLI tool.

Converters & Engines

Language	Status	Path	Notes
Python	✅ Canonical	py	Reference implementation and compatibility baseline
JavaScript	✅ Parity	js	Matches Python output on the tutorial corpus; harness available via SCION
Ruby	✅ Parity	ruby	Converter parity; engine trace interface under active development
Rust	✅ Parity	rust	Matches Python output on the tutorial corpus
Java	✅ Parity	java	Uses SCION-backed runner; matches Python output
Go	✅ Parity	go	Matches Python output on the tutorial corpus
Swift	✅ Parity	swift	Matches Python output on the tutorial corpus
C#	⚠️ Beta	csharp	Functional CLI; parity work in progress
Lua	✅ Parity	lua	Matches Python output on the tutorial corpus

See docs/COMPATIBILITY.md for the latest cross-language parity details and test notes.

Examples & Test Suite

This repo includes a curated set of canonical SCXML examples and their equivalent scjson forms in /examples. These are used for:

Functional validation (SCXML ↔ scjson ↔ SCXML)
Teaching state machine concepts via visual tools
Demonstrating usage in editors, UI libraries, and low-code platforms

These examples are derived from and/or adapted from:

📚 Included Tutorial (as Git Submodule)

We include Alex Zhornyak’s SCXML Editor Tutorial as a Git submodule under /tutorial.
This provides a rich set of canonical SCXML test cases and diagrams.

Attribution is provided for educational purposes. No endorsement is implied.
Source: https://alexzhornyak.github.io/ScxmlEditor-Tutorial/

🛠️ Submodule Setup

If you cloned this repo and /tutorial is empty, run:

git submodule init
git submodule update
Or clone with submodules in one step:

git clone --recurse-submodules https://github.com/your-org/scjson.git

This ensures you get the complete tutorial content alongside the examples and converters.

Converters

All converters share the same schema and test suite to ensure compatibility.

Getting Started

# Convert from SCXML to scjson
scjson convert --from scxml path/to/file.scxml --to scjson path/to/file.scjson

# Validate a scjson file
scjson validate path/to/file.scjson

Package Repostory Availability

pypi: [https://pypi.org/project/scjson/]

pip install scjson

npm: [https://www.npmjs.com/package/scjson]

npm install scjson
# harness requires scion-core
npm install scion-core

Harness (Node):

npx scjson-scion-trace -I path/to/chart.scxml -e events.jsonl --xml

rubygems: [https://rubygems.org/gems/scjson]

gem install scjson

RubyGems notes:

Ruby CLI includes converters and a trace interface. See docs/ENGINE-RB.md for engine usage and maturity. The gem is published at the link above.

cargo: [https://crates.io/crates/scjson]

cargo install scjson

dockerhub: [https://hub.docker.com/r/iraa/scjson] (Full development environment for all supported languages)

docker pull iraa/scjson:latest

For a full example of installing toolchains and dependencies across languages see codex/startup.sh.

Documentation

User guide (Python engine): docs/ENGINE-PY.md
Architecture & in-depth reference (Python): py/ENGINE-PY-DETAILS.md
Compatibility matrix: docs/COMPATIBILITY.md
Testing guide: TESTING.md
Agents overview: AGENTS.md

Known Divergences and Issues

Cross‑engine comparisons sometimes surface intentional, documented differences (e.g., ordering nuances, ECMA in semantics, history re‑entry). Use these resources to understand, normalize, and triage behavior across SCION (Node), Python, and Ruby:

Comprehensive overview: docs/COMPATIBILITY.md
Normalization profile: --norm scion in exec_compare sets leaf‑only, omit‑delta, omit‑transitions, strip‑step0‑states, and ordering=scion.
- Example: python py/exec_compare.py tests/exec/toggle.scxml --events tests/exec/toggle.events.jsonl --reference "node tools/scion-runner/scion-trace.cjs" --norm scion
CI known‑diffs list: scripts/ci_ruby_known_diffs.txt (used by scripts/ci_ruby_harness.sh --known to keep CI green while still reporting expected mismatches).
Ruby converter in CI: when Nokogiri isn’t available, the Ruby CLI falls back to the Python converter for SCXML↔scjson only; execution remains Ruby. See docs/ENGINE-RB.md (CI Notes).

Quick Installs.

Python Module

cd py
pip install -r requirements.txt
pytest -q

JavaScript Module

cd js
npm ci
npm test --silent

Ruby Module

cd ruby
gem install bundler
bundle install
bundle exec rspec

Go Module

cd go
go test ./...
go build

Rust Module

cd rust
cargo test

Swift Module

cd swift
swift test

C# Module

cd csharp
dotnet test -v minimal

Lua Module

cd lua
luarocks install luaexpat --deps-mode=one
luarocks install dkjson --deps-mode=one
luarocks install busted --deps-mode=one
busted tests

Legal and Documentation

All source code in this directory is released under the BSD 1-Clause license. See LICENSE and LEGAL.md for details. Additional documentation is available in AGENTS.md and TESTING.md.
